Product Details
Carbide grade for drawing dies
|
Grade
|
Density(g/cm3)
|
Hardness(HRA)
|
TRS(MPa)
|
Applications recommended
|
|
YG6X
|
14.95
|
91.5
|
1800
|
For drawing steel and nonferrous wires or bars of less than ￠6.00mm under not so much stress.
|
|
YG6
|
14.95
|
90.5
|
1900
|
For drawing steel, nonferrous alloy bars of less than ￠20.00mm under more stress and also for drawing tubes of less than ￠10.00mm.
|
|
YG8
|
14.8
|
89.5
|
2200
|
For drawing steel and nonferrous bars and tubes, also for manufacturing mechanical parts, tools and wear parts.
|
|
YG10
|
14.5
|
88.5
|
2400
|
|
YG15
|
14.0
|
87.0
|
2800
|
For drawing steel bars and tubes with a high reduction rate and for manufacturing anvils, drilling and punching and impacting.
|
|
|
|
Note: We supply the drawing dies according to the drawing provided by customers.
Customization Service
In addition to standard specifications, we offer comprehensive customization including special sizes, special shapes, custom material formulations, and surface coating treatments. Please contact us via the inquiry form or by phone with your specific requirements.
